Solid State Insulator, Transistor Insulator

Solid state or transistor insulators provide a non-metallic insulating surface between an electrical component, such as a diode or transistor, and its mounting surface. They are available in a variety of styles to match the various configurations of these components.

Use our Quick Search below to source kapton, mica and Mylar® transistor insulators from our wide selection of options.

Available Materials: Fiberglass, Kapton, Mica, Mylar®

Customary Finishes: No Finish

Not all available materials are listed in our catalog for every part number. If you require a different material or size, please submit a quote.

If you need additional information on your particular transistor insulator application click on one of the links below:
     View our material & finish specification sheets
     View non-metallic material characteristic information
     View finish characteristic information

Did you know?Seastrom has extensive custom capabilities in Precision Stamping, CNC Machining, Multi-Spindle Screw Machining, Four-Slide, Water Jet & Laser Part Marking to meet all your requirements. Products can be manufactured in most metallic and non-metallic materials, even hard to find materials. Ask us today!

Quick Search

Material

Min A

Max A

Min C

Max C

All Available PartsOnly Parts in Stock

Don't see what you need?

Click here to revise your search

Click here to request a custom quote

Click on the Column Name to re-sort data.

Dimensions in Inches

Product Number	A	C	F	G	H	T	Case Style	Material	Stock	Leadtime	Get Pricing
5206-5	0.245	0.036	0.031	0.031	0.031	0.002		Mylar ®	0	6-7 Weeks	Price
5206-6	0.245	0.036	0.031	0.031	0.031	0.002		Mica	0	6-7 Weeks	Price
5206-7	0.245	0.036	0.031	0.031	0.031	0.002		Kapton	0	6-7 Weeks	Price
5206-14	1.125	0.345	0.140	0.200	0.156	0.003	To 36	Mica	0	6-7 Weeks	Price
5206-15	1.125	0.345	0.143	0.200	0.194	0.003	To 36	Mica	0	6-7 Weeks	Price
5206-16	1.187	0.345	0.140	0.200	0.156	0.003	To 36	Mica	0	6-7 Weeks	Price
5206-1	1.187	0.345	0.187	0.250	0.187	0.002	To 36	Mica	0	6-7 Weeks	Price
5206-8	1.187	0.345	0.187	0.250	0.187	0.003	To 36	Kapton	0	6-7 Weeks	Price
5206-9	1.200	0.345	0.120	0.190	0.140	0.003	To 36	Kapton	0	6-7 Weeks	Price
5206-2	1.200	0.345	0.120	0.190	0.140	0.003	To 36	Mica	0	6-7 Weeks	Price
5206-3	1.250	0.345	0.141	0.203	0.156	0.002	To 36	Mica	0	6-7 Weeks	Price
5206-10	1.250	0.345	0.141	0.203	0.156	0.003	To 36	Kapton	245	In Stock - Ready To Ship!	Price
5206-11	1.620	0.345	0.195	0.195	0.195	0.003	To 36	Kapton	0	6-7 Weeks	Price
5206-12	1.620	0.345	0.140	0.200	0.156	0.003	To 36	Mica	0	6-7 Weeks	Price
5206-13	1.620	0.345	0.187	0.187	0.187	0.003	To 36	Mica	0	6-7 Weeks	Price
5206-4	1.620	0.345	0.195	0.195	0.195	0.002	To 36	Mica	0	6-7 Weeks	Price
